Γεμίζοντας και σφραγίζοντας μηχανή αυτόματων σωλήνων
Created with Pixso.

Chinese Manufacturer Automatic Tube Filling Sealing for Toothpaste Plastic Tube Tube Filling Machine

Chinese Manufacturer Automatic Tube Filling Sealing for Toothpaste Plastic Tube Tube Filling Machine

Ονομασία μάρκας: LTPM China
Αριθμός μοντέλου: LTRG-Σειρά
MOQ: 1 σετ
τιμή: Διαπραγματεύσιμα
Όροι πληρωμής: L/C, T/T
Ικανότητα εφοδιασμού: 15 Σετ/Μήνας
Πληροφορίες λεπτομέρειας
Τόπος καταγωγής:
Κίνα
Πιστοποίηση:
CE
Αυτόματος βαθμός:
Αυτόματο
Δυναμικό:
380(220)V/50Hz
Υλικό:
SUS 304/316L
Παραγωγική ικανότητα:
25-40 τμχ / λεπτό
Μοτέρ:
1,5 kw
Ύψος σωλήνα:
50-250mm
Βάρος:
300 κιλά
Διάσταση (Μ*Π*Υ):
1500*700*1800 χλστ
Συσκευασία λεπτομέρειες:
Export Standard Ξύλινη θήκη
Δυνατότητα προσφοράς:
15 Σετ/Μήνας
Επισημαίνω:

automatic toothpaste tube filling machine

,

plastic tube sealing machine

,

Chinese tube filling machine manufacturer

Περιγραφή του προϊόντος
Introduction
The automatic tube flling machine is mainly used to flling ointment materials into cylindrical, capped tubes of Aluminum or Composite and seal the tubes ends. In compliance with the standard of GMP dosing pump is a new type stainless steel butterfly valve for ointment flling a screw fine adjustment device is privided, so the ointment weighing is accurate. Thanks to the Adption of the sophisticated accurately and reliably, change frequency to control the machine speed, Used FuKaiShen index drives and international advanced tube sealing systems.

Product Parameter
Power Supply 50Hz/380V 3P
Speed 80-120 pieces/min
Filling Range 3-250 g
Pipe Length 50-210mm
Pipe Diameter 13-50mm
Pressure 0.5-0.6MPa
Machine Size 2550mmx1420mmx2115mm
Weight 2200Kg



Product Structure

Chinese Manufacturer Automatic Tube Filling Sealing for Toothpaste Plastic Tube Tube Filling Machine 0
